Bergmann C807s

The new generation with Tier 5 final engine.

The Bergmann C807s, one of the most successful dumpers in its class, has now been equipped with an economical, clean and quiet running Tier 5 final engine. This is in addition to the existing: floating rear axle for increased driving comfort and transport performance. And the weather roof with front windscreen that can be lowered for transport on standard flat bed trucks (transport height under 2.6 m). For significantly reduced transport costs compared with conventional transport on a low loader.

Bergmann C807s Dumpers

Compact and maneuverable.

Bergmann C807s Dumper Features

Technical data.

Bergmann C807s | Compact dumper

Safety bar (ROPS) Lowerable canopy (ROPS) Full cab
Payload 13,228 lb 13,228 lb 13,228 lb
Capacity level 3.3 yd³ 3.3 yd³ 3.3 yd³
Capacity Heaped 4.7 yd³ 4.7 yd³ 4.7 yd³
Total length 15.01 ft 15.01 ft 15.01 ft
Total width 6.70 ft 6.70 ft 6.70 ft
Clearance height 10.80 ft 10.58 ft 10.58 ft
Ground clearance 1.07 ft 1.07 ft 1.07 ft
Dumping height 3.74 ft 3.75 ft 3.74 ft
Load height 6.11 ft 6.11 ft 6.11 ft
Engine power 55 kW 55 kW 55 kW
Empty weight 9,480 lb 9,811 lb 10,141 lb

Download C807s brochures.
